The mixer is equipped with a rubber belt

Previous Next

type	XK-160	XK-230	XK-250	XK-300	XK-360	XK-400
(mm) Working diameter of rolis	160	230	250	300	360	400
( mm) Working length of rolls	320	600	620	750	900	1000
（m/min) Front roll surface speed	8.95	10.21	14.1	15.1	16.25	18.65
Friction ratio	1:1.35	1:1.19	1:1.17	1:1.25	1:1.25	1:1.19
Max.nip( mm)	4.5	7	8	10	10	10
Capacity per.batch( kg)	1～2	6～10	8～15	15～20	20～25	18～35
Motor power (kw)	5.5	15	18.5	22	30	37
Overall dimension: Length×Wid th×Height	1380×860x1320	2800×1200×1120	3400×1500×1500	3450×1500×1550	3780×1850×1750	4350×1850×1785
